PRESSURE WASHERS | HOT WATER
- 25 lt fuel tank with level float
- High-pressure detergent suction with proportional detergent regulation
- 4 Ø 300 anti puncture pneumatic wheels + brake
- Water tank with cartridge filter and floater
- Anti-scale device with pump and tank (2.5 l)
- Professional 4-pole motor (1400 giri/min) with flexible joint and thermal protection
- Professional pressure unloader valve
- 15 seconds Delayed Total Stop
- General stop when the machine is not used for a long time (20 minutes)
- Boiler with stainless steel casing
- Electronic temperature regulation system with high precision of the set value • PED 2014/68/CE cat. II certification
- Flow-switch controlled burner
- Safety valve
- Boiler thermal protection
- Pressure gauge with S.S. frame
- Professional control panel with:
- Power supply led and low voltage alarm
- Amperometric control with overcurrent alarm
- Microleaks detection system
- Ordinary maintenance alarm
- Burner malfunction alarms
TECHNICAL FEATURES
| Product Code | 36031-00012 |
| Pressione di esercizio (bar) | 30÷190 |
| Max pressure (bar) | 200 |
| Water flow (l/h) | 500÷1260 |
| Max water flow (l/h) | 1260 |
| Power Consumption (kW) | 9.8 |
| Electrical power supply (V-Hz) | 400-50 |
| Motorpump/RPM | RW / 1400 |
| Potenza termica motore (kW) | 7.3 |
| Inlet water temperature (°C) | 60 |
| Temperatura max. uscita (°C) | 85÷140 |
| Serbatoio combustibile caldaia (l) | 25 |
| Consumo combustibile caldaia (l/h) | 8.2 |
| High pressure hose (m) | 10 |
| Dimensions (cm) | 110x75x103 |
| Weight (Kg) | 200 |
| Box dimension (cm) | 135 x 88 x115 |
| Quantity for pallet | 1 |
| n° machines container 20' | 17 |
| n° macchine in box da 40 (40 HQ) floor loaded | 39 |
| Dispositivo anticalcare |
