PRESSURE WASHERS | COLD WATER
- Heavy duty structure with stainless steel cover
- High filtering capacity cartridge self-cleaning suction filter
- Pressure gauge with stainless steel casing
- Hot water seals
- 4-poles (1400 rpm) motor well oversized and protected with paint
- Pneumatic wheels with steel hub and air chamber
- Highly professional unloader valve with external bypass
- Motor-pump coupling by means of a flexible joint
- FLOW-SENSITIVE Delayed Total Stop
- Low voltage control panel
- Contactor
- Thermal relay motor protection
TECHNICAL FEATURES
Product Code | 36019-00033 |
Pressione di esercizio (bar) | 50÷250 |
Max pressure (bar) | 260 |
Water flow (l/h) | 440÷1260 |
Max water flow (l/h) | 1260 |
Power Consumption (kW) | 10 |
Electrical power supply (V-Hz) | 400-50 |
Motorpump/RPM | SW / 1400 |
Potenza termica motore (kW) | 8.8 |
Inlet water temperature (°C) | 85 |
High pressure hose (m) | 10 |
Dimensions (cm) | 90x75x95 |
Weight (Kg) | 161 |
Box dimension (cm) | 90 x 80 x 115 |
Quantity for pallet | 1 |
n° machines container 20' | 28 |
STANDARD EQUIPMENT
OPTIONAL EQUIPMENT
PLUS
DOCUMENTS
